INTERIOR FLOOR
INSIDE WALL
SLEEVE
AREA BETWEEN
(INSULATED)
WALL AND SLEEVE
OUTSIDE WALL
(SIZE VARIES)
OUTDOOR GRILLE
FILL INSULATION
I-TEC UNIT
(INSULATED)
DRAIN AREA
INSULATED WITH
6" BATT MATERIAL
MIS-2928 B
FIGURE 11B
UNIT MOUNTING
