Basler DECS-150 User Manual

25-34 9492600990
Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Configurable Protection 8
Stop Mode Inhibit
3512
Int32
4
R W
n/a
No=0 Yes=1
Configurable Protection 8
Threshold 1 Type
3514
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 8
Threshold 1 Pickup
3516
Float
4
R W
n/a
-999999 – 999999
Configurable Protection 8
Threshold 1
Activation Delay
3518
Float
4
R W
Second
0–300
Configurable Protection 8
Threshold 2 Type
3520
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 8
Threshold 2 Pickup
3522
Float
4
R W
n/a
-999999 – 999999
Configurable Protection 8
Threshold 2
Activation Delay
3524
Float
4
R W
Second
0–300
Configurable Protection 8
Threshold 3 Type
3526
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 8
Threshold 3 Pickup
3528
Float
4
R W
n/a
-999999 – 999999
Configurable Protection 8
Threshold 3
Activation Delay
3530
Float
4
R W
Second
0–300
Configurable Protection 8
Threshold 4 Type
3532
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 8
Threshold 4 Pickup
3534
Float
4
R W
n/a
-999999 – 999999
Configurable Protection 8
Threshold 4
Activation Delay
3536
Float
4
R W
Second
0–300
Configurable Protection 8
Label
3538
String
16
R W
n/a
0–16
Hardware Shutdown
OEL Shutdown
Enable
3546
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
OEL Shutdown
Delay
3548
Float
4
R W
Second
0–30
Hardware Shutdown
UEL Shutdown
Enable
3550
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
UEL Shutdown
Delay
3552
Float
4
R W
Second
0–30
Hardware Shutdown
SCL Shutdown
Enable
3554
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
SCL Shutdown
Delay
3556
Float
4
R W
Second
0–30
Hardware Shutdown
27 Shutdown
Enable
3558
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
59 Shutdown
Enable
3560
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
81O Shutdown
Enable
3562
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
81U Shutdown
Enable
3564
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
EDM Shutdown
Enable
3566
Unit32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
Field Overvoltage
Shutdown Enable
3568
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Hardware Shutdown
Field Short Circuit
Shutdown Enable
3570
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Gains Settings
Table 25-13. Gains Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Primary Gain Option
3800
Uint32
4
R W
n/a
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18
