Basler DECS-150 User Manual

9492600990 25-35
DECS-150 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
Secondary Gain Option
3802
Uint32
4
R W
n/a
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18
AVR Kp Primary
3804
Float
4
R W
n/a
0–1000
AVR Ki Primary
3806
Float
4
R W
n/a
0–1000
AVR Kd Primary
3808
Float
4
R W
n/a
0–1000
AVR Td Primary
3810
Float
4
R W
n/a
0–1
FCR Kp
3812
Float
4
R W
n/a
0–1000
FCR Ki
3814
Float
4
R W
n/a
0–1000
FCR Kd
3816
Float
4
R W
n/a
0–1000
FCR Td
3818
Float
4
R W
n/a
0–1
PF Ki
3820
Float
4
R W
n/a
0–1000
PF Kg
3822
Float
4
R W
n/a
0–1000
Var Ki
3824
Float
4
R W
n/a
0–1000
Var Kg
3826
Float
4
R W
n/a
0–1000
OEL Ki
3828
Float
4
R W
n/a
0–1000
OEL Kg
3830
Float
4
R W
n/a
0–1000
UEL Ki
3832
Float
4
R W
n/a
0–1000
UEL Kg
3834
Float
4
R W
n/a
0–1000
SCL Ki
3836
Float
4
R W
n/a
0–1000
SCL Kg
3846
Float
4
R W
n/a
0–1000
Vm Kg
3840
Float
4
R W
n/a
0–1000
AVR Kp Secondary
3842
Float
4
R W
n/a
0–1000
AVR Ki Secondary
3844
Float
4
R W
n/a
0–1000
AVR Kd Secondary
3846
Float
4
R W
n/a
0–1000
AVR Td Secondary
3848
Float
4
R W
n/a
0–1
AVR Ka Primary
3850
Float
4
R W
n/a
0–1
AVR Ka Secondary
3852
Float
4
R W
n/a
0–1
FCR Ka
3854
Float
4
R W
n/a
0–1
PSS Settings
Table 25-14. PSS Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
PSS Enable
4300
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary M
4302
Uint32
4
R W
n/a
1–5
PSS Primary N
4304
Uint32
4
R W
n/a
0–1
PSS Primary Switch 0
4306
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Switch 1
4308
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Switch 3
4310
Uint32
4
R W
n/a
Frequency=0 Der. Speed=1
PSS Primary Switch 4
4312
Uint32
4
R W
n/a
Power=0 Der. Freq/Speed=1
PSS Primary Switch 5
4314
Uint32
4
R W
n/a
Exclude=0 Include=1
PSS Primary Switch 6
4316
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Switch 7
4318
Uint32
4
R W
n/a
Off=0 On=1
PSS Primary Switch 8
4320
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Switch 9
4322
Uint32
4
R W
n/a
Exclude=0 Include=1
PSS Primary Switch 10
4324
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Switch 11
4326
Uint32
4
R W
n/a
Disabled=0 Enabled=1
PSS Primary Tw1
4328
Float
4
R W
Second
1–20
