Basler DECS-150 User Manual

25-38 9492600990
Modbus
®
Communication DECS-150
Name
Register
Type
Bytes
R/W
Unit
Range
PSS Secondary Power
Level Threshold
4490
Float
4
R W
n/a
0–1
PSS Secondary Power
Level Hysteresis
4492
Float
4
R W
n/a
0–1
PSS Secondary Tw3
4494
Float
4
R W
Second
1– 20
PSS Secondary Tw4
4496
Float
4
R W
Second
1–20
PSS Secondary Tl2
4498
Float
4
R W
Second
0.01–20
PSS Secondary Kpe
4500
Float
4
R W
n/a
0–2
PSS Secondary Tl3
4502
Float
4
R W
Second
0.05– 20
PSS Secondary Tr
4504
Float
4
R W
Second
0.01–1
PSS Enable Status
4506
Uint32
4
R
n/a
Off=0 On=1
Grid Code Settings
Table 25-15. Grid Code Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Grid Code Enable
4800
Uint32
4
R W
n/a
Disabled=0
Enabled=1
Grid Disconnect Time Delay
4802
Float
4
R W
Second
0–3600
Min Freq Normal
4804
Float
4
R W
Hertz
40–70
Max Freq Normal
4806
Float
4
R W
Hertz
40–70
Min V Bus Normal
4808
Float
4
R W
Per Unit
0.1–1
Max V Bus Normal
4810
Float
4
R W
Per Unit
1–1.3
Min Freq Disconnect
4812
Float
4
R W
Hertz
40–70
Max Freq Disconnect
4814
Float
4
R W
Hertz
40–70
Min V Bus Disconnect
4816
Float
4
R W
Per Unit
0.1–1
Max V Bus Disconnect
4818
Float
4
R W
Per Unit
1–1.3
PF Reference
4820
Float
4
R W
Power Factor
-1 – 1
Q Limit U Point 1
4822
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 2
4824
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 3
4826
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 4
4828
Float
4
R W
Per Unit
0.8–1.2
Q Limit Q Point 1
4830
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 2
4832
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 3
4834
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 4
4836
Float
4
R W
Per Unit
-0.4 – 0.4
Q(U) Slope
4838
Float
4
R W
Per Unit
0–20
Q(U) V Bus for Zero Q
4840
Float
4
R W
Per Unit
0.9–1.1
Q(U) Deadband
4842
Float
4
R W
Per Unit
0–0.1
Q(U) Max
4844
Float
4
R W
Per Unit
-0.4 – 0.4
Q(U) Min
4846
Float
4
R W
Per Unit
-0.4 – 0.4
Q(P) Point P01
4848
Float
4
R W
Per Unit
0–1.5
Q(P) Point P02
4850
Float
4
R W
Per Unit
0–1.5
Q(P) Point P03
4852
Float
4
R W
Per Unit
0–1.5
Q(P) Point P04
4854
Float
4
R W
Per Unit
0–1.5
Q(P) Point P05
4856
Float
4
R W
Per Unit
0–1.5
Q(P) Point P06
4858
Float
4
R W
Per Unit
0–1.5
Q(P) Point P07
4860
Float
4
R W
Per Unit
0–1.5
Q(P) Point P08
4862
Float
4
R W
Per Unit
0–1.5
Q(P) Point P09
4864
Float
4
R W
Per Unit
0–1.5
Q(P) Point P10
4866
Float
4
R W
Per Unit
0–1.5
Q(P) Point Q01
4868
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q02
4870
Float
4
R W
Per Unit
-0.7 – 0.7
