Basler DECS-150 User Manual

9492600990 25-39
DECS-150 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
Q(P) Point Q03
4872
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q04
4874
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q05
4876
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q06
4878
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q07
4880
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q08
4882
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q09
4884
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q10
4886
Float
4
R W
Per Unit
-0.7 – 0.7
Remote Control Fail Mode
4888
Uint32
4
R W
n/a
Q(PF) Control=0
Hold Value=1
Remote Failure Time Delay
4890
Float
4
R W
Second
0–600
APC Enabled
4892
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Active Power Input Source
4894
Uint32
4
R W
n/a
Active Power Setpoint=0
Active Power Selection=1
Active Power Setpoint
4896
Float
4
R W
Per Unit
-2 – 2
APC Normal Power Increase Rate
Percent
4898
Float
4
R W
Percent Per
Second
0.07–10
APC Normal Power Decrease Rate
Percent
4900
Float
4
R W
Percent Per
Second
0.07–10
LVRT Option
4902
Uint32
4
R W
n/a
Disabled=0
Q(PF) Control=1
Q(Voltage Limit) Control=2
Q(U) Control=3
Q(P) Control=4
Q Remote Control=5
LVRT Enabled
4904
Uint32
4
R W
n/a
Disabled=0
Enabled=1
Time Constant for PT1
4906
Float
4
R W
Second
0.01–60
LFSM Enabled
4908
Uint32
4
R W
n/a
Disabled=0
Enabled=1
LFSM U Deadband
4910
Float
4
R W
Hertz
40–70
LFSM O Deadband
4912
Float
4
R W
Hertz
40–70
LFSM U Max Power Limit Derate
Percent
4914
Float
4
R W
Percent Per
Hertz
0–20
LFSM O Max Power Limit Derate
Percent
4916
Float
4
R W
Percent Per
Hertz
0–20
LFSM U Droop Percent
4918
Float
4
R W
Percent Per
Hertz
16.67–100
LFSM O Droop Percent
4920
Float
4
R W
Percent Per
Hertz
16.67–100
APC Kg
4922
Float
4
R W
n/a
0–100
APC Ki
4924
Float
4
R W
n/a
0–100
APC PI Controller Max Limit
4926
Float
4
R W
Per Unit
-2 – 2
APC PI Controller Min Limit
4928
Float
4
R W
Per Unit
-2 – 2
Q(Third Party) Reference
4930
Float
4
R W
n/a
-0.45 – 0.45
Voltage Disconnect Time Delay
4932
Float
4
R W
Second
1–3600
Frequency Disconnect Time Delay
4934
Float
4
R W
Minute
1–60
Voltage Bus Time Constant
4936
Float
4
R W
Second
0.01–60
Q P Time Constant
4938
Float
4
R W
Second
0.01–60
Min Active Power Setpoint
4940
Float
4
R W
Per Unit
-2 – 2
Max Active Power Setpoint
4942
Float
4
R W
Per Unit
-2 – 2
PF Gain
4944
Float
4
R W
n/a
-100 – 100
Q Limit Gain
4946
Float
4
R W
n/a
-100 – 100
Q U Gain
4948
Float
4
R W
n/a
-100 – 100
Q Remote Gain
4950
Float
4
R W
n/a
-100 – 100
Q Limit Q Reference
4952
Float
4
R W
Per Unit
-0.45 – 0.45
Grid Reconnect Stability Timer
4954
Float
4
R W
Minute
0–30
