Basler DECS-150 User Manual

5-8 9492600990
Regulation DECS-150
Voltage Matching
BESTCOMSPlus Navigation Path: Settings Explorer, Voltage Matching, Voltage Matching
When enabled, voltage matching is active in AVR control mode and automatically adjusts the AVR mode
setpoint to match the sensed bus voltage. Voltage matching is based on two parameters: band and
matching level.
The Band setting defines the window in which the machine voltage must be for voltage matching to occur.
The Gen/Motor to Bus PT Match Level setting is provided to compensate for step-up or step-down
transformers in the system. The DECS-150 adjusts the sensed machine voltage by this percentage.
The Voltage Matching screen is illustrated in Figure 5-7.
Figure 5-7. Voltage Matching Screen
