Baumer PA408 Operating Instructions

PA408
26
www.baumer.com
Supply voltage
Connector Assignment
Connector 1 Supply voltage / –
Connector 2 Supply voltage / +
Input Current/Voltage
Connector 1 IN - / Sensor supply –
Connector 2 NC
Connector 3 NC
Connector 4 NC
Connector 5 20 mA IN +
Connector 6 Sensor supply +24 V
Connector 7 10 V / 200 V IN +
Input Pt100/Pt1000
Connector 1 Pt100 Commun / Pt1000
Connector 2 Pt100 / Pt1000
Connector 3 NC
Connector 4 Pt100
Connector 5 NC
Connector 6 NC
Connector 7 NC
Input Thermocouple J,K,T,N
Connector 1 Thermo-
Connector 2 Thermo+
Connector 3 NC
Connector 4 NC
Connector 5 NC
Connector 6 NC
Connector 7 NC

Baumer PA408 Specifications

General

Brand	Baumer
Model	PA408
Category	Monitor
Language	English
