Input potentiometer
Connector 1 Potentiometer -
Connector 2 Potentiometer Out
Connector 3 Potentiometer +
Connector 4 NC
Connector 5 NC
Connector 6 NC
Connector 7 NC
Input resistance
Connector 1 Common
Connector 2
IN 999,9...9999Ω
Connector 3
IN 50kΩ
Connector 4 NC
Connector 5 NC
Connector 6 NC
Connector 7 NC
Limit outputs/2 relay
Connector 1 Normally closed Relay 1
Connector 2 Changeover contact
Connector 3 Normally open
Connector 4 Normally closed Relay 2
Connector 5 Changeover contact
Connector 6 Normally open
Litz contact only by means of connector sleeves with insulating
enclosures for reasons of shock protection according to EN 61010.
Do not otherwise assign contacts that have been left unassigned
ex factory. We recommend to shield all sensor terminal leads and to
ground the shield on one side. Shields on both sides are recommen-
ded in case of RF interference or in case of equipotential bonding
over long distances. Sensor leads should not be in the same phase
winding as mains supply and output contact leads.
