Alimentation
Connecteur Désignation
Borne 1 Alimentation / –
Borne 2 Alimentation / +
Entrée courant/tension
Borne 1 IN - / Alimentation capteur –
Borne 2 NC
Borne 3 NC
Borne 4 NC
Borne 5 20 mA IN +
Borne 6 Alimentation capteur +24 V
Borne 7 10 V / 200 V IN +
Entrée Pt100/Pt1000
Borne 1 Pt100 Commun / Pt1000
Borne 2 Pt100 / Pt1000
Borne 3 NC
Borne 4 Pt100
Borne 5 NC
Borne 6 NC
Borne 7 NC
Entrée thermocouple J,K,T,N
Borne 1 Thermo-
Borne 2 Thermo+
Borne 3 NC
Borne 4 NC
Borne 5 NC
Borne 6 NC
Borne 7 NC
