3. Disconnect the earth wire.
4. Pull and lift the top panel.
5. Unhook the panel holding the control panel then place it on the boiler.
Fig.59
MW-4000261-1
3
Fig.60
MW-4000262-1
4
Fig.61
MW-4000263-1
5
5
7 Installation
7702630 - v02 - 11082018 POWER HT + 49
