Baxi POWER HT+ Series - Replacing the 6.3 A Fuses on the Electrical Terminal Blocks

10. Refit the insulating shell on the low-loss header.
11.3 Replacing the 6.3 A fuses on the electrical terminal blocks
Danger of electric shock
Before any work, switch off the mains supply to the boiler.
1. Pivot the fuse-holder socket N towards you.
Fig.192
MW-4000313-1
10
Fig.193
MW-3000228-01
1
11 Maintenance
7702630 - v02 - 11082018 POWER HT + 125
