25
AXE MASTER SETUP
4 - RIGHT POLE ASSY
Part # AAME29019-R
3 - LEFT POLE ASSY
Part # AAME29019-L
LOWER
SAFETY
WALL
P - RIGHT AXE ASSY
Part # AAAX29000-L
UPPER
SAFETY
WALL
MARQUEE
ASSEMBLY
O - LEFT AXE ASSY
Part # AAAX29000-L
B - SQUARE CON-
NECTOR PLATES (2)
Part # A5ME29021
8 - RIGHT WALL WIRE COVER
Part # WACA29082
7 - LEFT WALL WIRE COVER
Part # WACA29081
