Specifications
System
CPU
Socket LGA1150 supports Core i7/i5/i3 CPU up to 65W TDP
BIOS
AMI 64 Mb BIOS
System Chipset
Intel® Q87
I/O Chipset
Nuvoton NCT6106D
Memory
2 x 204 Pin SODIMM sockets supports1.5V DDR3 memory 1333/1600 MHz up to
16GB
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring temperatures, voltages, and cooling fan status. Auto throttling control
when CPU overheats
Expansion Slots
1 x PCI-E x16 slot (supports device up to10W)
2 x miniPCI slot (1 half size, 1 full size. Full size slot supports Mini-PCIe device or
mSATA SSD via jumper select)
DIO
16 Bit (8 in, 8 out)
S3 / S4
Yes
TPM
TPM1.2 (Infineon® TPM chip 9635 TT 1.2 on board)
Wake up on LAN or
Ring
LAN (PXE)
Smart Fan Control
Yes, CPU FAN, System FAN (4 pin type via SIO)
Display
Chipset
Intel® HD Graphics 4600 (GT2) integrated
Max. Resolution
2048 x 1536 bpp(@ 75Hz)
Dual Display Port
on Board
VGA
on board
DVI
on board, via level shifter
Audio
Audio Codec
Realtek® ALC892, 5.1 +2 with two independent Streaming
Audio Interface
Line in, Line Out, Mic-in
