Specifications Summary
Features
CPU
Socket LGA1150 supports Core i7/i5/i3 CPU up to 65W TDP
Chipset
Intel® Q87
Memory
2 x 204 Pin SODIMM sockets supports 1.5V DDR3 memory
1333/1600 MHz up to 16GB
Display
Intel® GMA HD 4600 (GT2)
Audio
Realtek® ALC892, 5.1 with Multiple Streaming HD Audio
LAN
Intel I210AT Gigabit Ethernet controller
Intel I217 Gigabit Ethernet controller
Expansion
1 x PCI-E x16 (supports device up to 10W)
2 x miniPCI-E x1
I/O
1 x VGA Port & 1 x DVI-D Port
2 x Display Port
1 x LVDS 24 bit / Dual Channel
4 x COM Port (pin header)
10 x USB Port (4 x USB3.0, 6 x USB2.0)
4 x SATA 6.0 Gp/s
1x LPT (pin header)
1x PS2 MS/KB (Optional)
Others
16 Bit GPIO (DIO) / Front audio / TPM 1.2
