20
1.6.5 Layout Content List
1.6.5.1 Slots
Label Function Note Page
DIMM1 240-pin DIMM slot 1 1. If there is only one memory
module being installed in the
system, install it on this slot first.
2. If there are only two memory
modules being installed in the
system, install these 2 modules
on “DIMM1” and “DIMM3” first.
31
DIMM2 240-pin DIMM slot 2 If you have only one memory
module being installed in the
system, install the module on
“DIMM2”
31
DIMM3 240-pin DIMM slot 3 If there are only two memory
modules being installed in the
system, install these 2 modules
on “DIMM1” and “DIMM3” first.
31
DIMM4 240-pin DIMM slot 4 31
Slot1 PCI express x16 slot 51
Slot3 PCI express x4 slot 51
Slot2 PCI express x1 slot 51
Slot4 PCI slot 51
1.6.5.2 Internal Jumpers
Label Function Note Page
JP5 Clear CMOS 3 x 1 header, pitch 2.54mm 48
JP2, JP3, JP4 COM1 RS232/RS422/RS485 Select 3 x 2 header, pitch 2.00mm 48
COM_JP1
COM_JP2
COM_JP3
COM_JP4
COM_JP5
COM_JP6
COM1, COM2, COM3, COM4
RI/+5V/+12V Select
3 x 2 header, pitch 2.00mm 49
AT_ATX1 AT/ATX Power Select 3 x 1 header, pitch 2.54mm 49
