1.6.5.3 Internal Headers
Label Function Note Page
PWR1 ATX Power Connector 2 x 2 header 47
ATX1 ATX Power Connector 12 x 2 header 47
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
Serial ATA Connectors 1~6 7-pin header 38
CPU_FAN (CN7) CPU Fan Connector 4 x 1 wafer, pitch 2.54mm 28
CHA_FAN1 (CN3) Chassis Fan Connector 4 x 1 wafer, pitch 2.54mm 39
SYS_FAN1 (CN4) System Fan Connector 4 x 1 wafer, pitch 2.54mm 39
INTR1 Chassis Intrusion Connector 2 x 1 header, pitch 2.54mm 42
J_AUDIO1 Front Panel Audio Connector 5 x 2 header, pitch 2.54mm 43
CN14 Amplifier Connector 4 x 1 header, pitch 2.54mm 44
JUSB_1
JUSB_2
JUSB_3
JUSB_4
JUSB_5
USB 2.0 Connector 5 x 2 header, pitch 2.54mm 44
COM1
COM2
COM3
COM4
COM5
COM6
Serial Port Connector 1, 2, 3, 4,5,6 5 x 2 header, pitch 2.00mm 45
LPT Parallel Port Connector 13 x 2 header, pitch 2.00mm 45
FP1 System Panel Connector 5 x 2 header, pitch 2.54mm 43
CN6 Digital I/O header 10 x 2 header, pitch 2.54mm 44
CN2 SPI pin header (Factory use only) 4 x 2 header, pitch 2.54mm 44
CN1 Reserved 2 x 7 header, pitch 2.0mm
