BCM RX87Q - Page 9

9
Mainboard Specifications
Model RX87Q
Processor Socket LGA1150 supports 4
th
Generation Core i7/i5/i3 CPU (up to 84W)
Chipset Intel® Q87
Memory
4 x 240 Pin DIMM sockets supports DDR3 memory module (1.5V) 1333 (PC3-16000)/
Display Intel® GMA HD (Must use Intel Processor that provides “Intel HD Graphics”
SATA 6 x SATA III connectors supports Data Transfer rates 6.0Gb/s, 3.0Gb/s and 1.5Gb/s
PCI-E 1x PCI-E x 16 slots (Slot “PCIEX16”)
1 x PCI-E x4 slot (Slot “PCIEX4_1”)
1 x PCI-E x1 Slots (Slot “PCIEX1_1”, “PCIEX1_2”)
PCI 3 x PCI Slots (PCI 2.3 compliant)
USB 10 x USB 2.0 ports (5 x header)
4 x USB3.0 ports (4x rear I/O)
TPM Infineon® TPM Chip 9635
1 x TPM 1.2 Security Device
Super I/O Controller Fintek® F81866AD-I
Serial Ports 6 x RS232 ports (internal header)
LPT 1 x LPT header
Watch Dog Timer 1 ~ 255 sec timer
HW Monitor Yes
Audio Realtek® ALC887
HD Audio Codec with auto jack sensing
LAN Intel® 217LM Gigabit PHY
1 x 10/100/1000 LAN
Intel® 210AT PCI-E Gigabit LAN
1 x 10/100/1000 LAN
BIOS AMI™ BIOS
AMI™ Aptio BIOS with 32Mb SPI ROM
Expansion Slots
PCI-E 1 x PCI-E x 16 slot
PCI 1 x PCI slot
