BEA FALCON - Sensing Field Configuration; Sensing Field Visualization; LED Status Indicators

75.5351.02 EN 20080317 (75.5350) Page 3 of 7
FALCON (Mounting height: 16.5 feet)
The sensing fields here on the
right correspond to the
following adjustments:
• tilt angle: 15°, 30°, 45°
• sensitivity: 9.
The sensing fields here on the
right correspond to the following
adjustments:
• tilt angle: 30°
• sensitivity: 9, 6, 3
FALCON (Mounting height: 11.5 feet)
The sensing fields here on the
right correspond to the
following adjustments:
• tilt angle: 15°, 30°, 45° ;
• sensitivity: 9.
The sensing fields here on the
right correspond to the
following adjustments:
• tilt angle: 30°
• sensitivity: 9, 6, 3
FALCON XL (Mounting height: 8 feet)
The sensing fields here on the
right correspond to the
following adjustments:
• tilt angle: 15°, 30°, 45° ;
• sensitivity: 9.
The sensing fields here on the
right correspond to the
following adjustments:
• tilt angle: 30°
• sensitivity: 9, 6, 3
• When the power is turned ON, the red and green LEDs flash for few seconds.
• During a detection the red LED lights on.
• During configuration, the red LED flashes a number of times corresponding to the parameter being
changed (see next table). The green LED flashes a number corresponding to its setting.
SETTING
THE SENSING
FIELD
DIMENSIONS
LED SIGNAL
6 3 0 3 6
3
6
9
12
15
18
21
3
6
9
12
15
18
21
H = 16.5 ft.
S = 9
6 3 0 3 6
3
6
9
1
2
1
5
1
8
2
1
3
6
9
12
15
18
21
H = 16.5 ft.
A
ngle = 30
°
6 3 0 3 6
3
6
9
12
15
18
21
3
6
9
12
15
18
21
H = 11.5 ft.
S = 9
6 3 0 3 6
H = 11.5 ft.
A
ngle = 30
°
3
6
9
12
15
3
6
9
12
15
6 3 0 3 6
H = 8 ft.
S = 9
3
6
9
12
15
3
6
9
12
15
6 3 0 3 6
H = 8 ft.
A
ngle = 30
°
3
6
9
12
15
3
6
9
12
15
