14
1
4
7
F1 F2
5
8
0
+
?
3
6
9
2 A
B
C
D
15
16
Application requires an access
code or sensor will not unlock
after entering an access code.
You must enter a code or the wrong
code was entered.
Cycle the power. No code is required to
unlock during the rst minute after pow-
ering on. Unlock, then lock and enter a
new access code or “0000” to delete the
current access code.
TROUBLESHOOTING (CONTINUED)
SYMPTOMS
POSSIBLE CAUSES CORRECTIVE ACTION
The green LED is on during rain
or snow.
The sensor detects objects
outside of its detection eld.
The sensor does not respond to
the remote control.
The microwave detection is disturbed
by the rain or snow.
To much reection due to a metallic
environment.
The batteries in the remote control are
not installed properly, dead or the re-
mote is poorly aimed.
Increase the microwave rejection.
Consider using the unidirectional mode
under the Detection Mode.
Increase the microwave rejection.
Verify or replace batteries or aim remote
towards sensor.
The sensor is not powered.
Check the power supply of the sensor.
ACCESSORIES
Spotnder
P/N: 10SPOTFINDER
Remote control
P/N: 10REMOTE
Telescoping HD Bracket
P/N: 10HDBRACKET
COMPANY CONTACT
Our Service Technicians can be called 24 hours a day, 7 days a week. For more information visit www.beasensors.com.
Do not leave problems unresolved. If a satisfactory solution cannot be achieved after troubleshooting
a problem, please call BEA, Inc. If you must wait for the following workday to call BEA, leave the door
inoperable until satisfactory repairs can be made. Never sacrifice the safe operation of the automatic
door or gate for an incomplete solution.
After Normal Business Hours
West / Mexico
1-888-419-2564
Central
1-800-407-4545
AK, MI, WI, TX, Canada
1-866-836-1863
East
1-866-249-7937
Phone: 1-800-523-2462 Fax: 1-888-523-2462
For email support contact us at: Tech_Services@beainc.com
Transformer
P/N: 1024VAC
75.5695.01 EN 20120113 Page 9 of 9
