75.5782.08 IXIO-ST 20230913 Page 3 of 12
TECHNOLOGY / PERFORMANCE
Detection mode Presence
typical response time: < 200 ms (max: 500 ms)
Technology Active infrared with background analysis
Spot: 2” × 2” (typ)
Number of spots: max. 24 per curtain
Number of curtains: 2
Mounting height: 6’6” – 11’6”
local regulations may impact acceptable mounting height (pedestrian
applications only)
Sensor temperature range: -13 – 131 °F *
0 – 95% relative humidity, non-condensing
LCD screen is operational from 14 – 131 °F.
The sensor may still be programmed in colder temperatures, but with
the remote control.
ELECTRICAL
Output
Relay 1 Electromechanical relay (potential and polarity free)
Max. contact current: 1 A
Max. contact voltage: 30 VAC
Adjustable hold time: 0.5 – 9 s
Relay 2 Solid-state relay (potential and polarity free)
Max. contact current: 100 mA
Max. contact voltage: 42 VDC / 30 VAC
Test/Monitoring input: Sensitivity:
Low: < 1 V
High: > 10 V (max. 30 V)
Response time on test request: typical < 5 ms
Supply voltage: 12 – 24 VAC ±10%
12 – 30 VDC ±10%
to be operated from SELV-compatible power supplies only
Power consumption: < 2.5 W
Noise: < 70 dB
PHYSICAL
Degree of protection: IP54
COMPLIANCE
Compliance: ISO 13849 PL «c» CAT. 2
(under the condition that the door control system monitors the sensor at
least once per door cycle)
TECHNICAL SPECIFICATIONS
Specifications are subject to change without prior notice.
All values measured in specific conditions.
