BEA INSTALLATION/SERVICE COMPLIANCE EXPECTATIONS
Technology: laser, time-of-flight measurement
Detection mode: presence
Detection width: 20 – 48” (measured from leading edge to sensor LED)
Mounting Height: 75 – 98” (measured from finished floor to sensor LED)
Remission factor: > 2%
Angular resolution: 2.56°
Testbody: 28” (H) x 12” (W) x 8” (D)
Emission characteristics:
IR laser: wavelength 905 nm; max. output pulse power 35 W (CLASS 1)
Supply Voltage: 12 – 30 VDC (15 W Class II)
Power Consumption: < 15 W
Response time: typ. 40 ms (max. 80 ms)
Output:
Rating:
4 electro-mechanic relays (galvanic isolated - polarity free)
All outputs Class 2 supply, 12 – 24 VAC / 12 – 30 VDC, max. 15 W
Input:
Rating:
2 optocouplers (galvanic isolated – polarity-free)
12 – 24 VAC / 12 – 30 VDC, 50/60 HZ, max. 15 W
Test Input*: 8 – 15 VDC
Temperature Range: -13 – 121 °F (-25 – 55 °C)
Degree of Protection: Hub: IP20/NEMA 1
Sensor: IP53/NEMA 3
Humidity: 0 – 95% non-condensing
Vibrations: < 2 G
Material: PC/ASA
Norm Conformity: EN 60825-1-Eye-safety class 1 IR laser (905 nm), UL60730,
UL 10B/C Fire Rated 3hrs (file #R39071)
Mounting angle (rotational): 35° fixed
Tilt angle: 0 – 5° (for angles less than 5°, contact Tech Support)
Pollution on front screens: max. 30%; homogenous
Specifications are subject to change without prior notice.
All values have been measured in specific conditions.
* SEE APPLICATION NOTES OR CONTACT BEA FOR TECHNICAL SUPPORT
PLEASE KEEP FOR FURTHER USE - DESIGNED FOR COLOR PRINTING
©BEA | Original Instructions | 75.5753.15 LZR-MICROSCAN T 20180720
TECHNICAL SPECIFICATIONS
