BEA ULTIMO - Page 2

1
2
3
4
5
6
7
8
9
10
11
12
Page 2 of 20 75.0034.03 ULTIMO 20220120
1. cover
2. light pipe
3. radar antenna
4. AIR receiver
5. AIR emitter
6. LCD
7. [for internal use only]
8. LED
9. AIR curtain angle adjustment knob
10. main adjustment knob
11. main connector
12. [for future development]
DESCRIPTION
