BEA ULTIMO - Technical Specifications

75.0034.03 ULTIMO 20220120 Page 3 of 20
Mounting height 6’6” – 11’6”
typical: 7'2"
Detection mode motion and presence
Technology microwave doppler radar and active infrared (AIR) with background analysis
Radar detection speed (min) 2 in/s
AIR response time (typ.) < 200 ms (max. 500 ms)
Radar transmitter
frequency
radiated power
power density
lobe angles
24.150 GHz
< 20 dBm EIRP
< 5 mW/cm
2
0 – 45° (typical adjustment), default 25°
AIR spots
size
number of spots
number of curtains
curtain angles
2” × 2” (typ.)
max. 32 per curtain
3
-3 – 11°, default 0°
Relay output 1
max. contact current
max. contact voltage
adjustable hold time
electromechanical relay (potential- and polarity-free)
1 A
30 VDC
0.5 – 9 seconds
Optofet output 2
max. contact current
max. contact voltage
hold time
solid-state relay (potential- and polarity-free)
400 mA
42 VAC/VDC
0.3 – 1 second
Test/Monitoring input
sensitivity
response time on request
low: < 1 V high: > 10 V (max. 30V)
<5 ms (typ.)
Supply voltage 12 – 24 VAC ±10%
12 – 30 VDC ±10%
Power consumption < 3.2 W
Temperature range -13 – 131 °F *
0 – 95% relative humidity, non-condensing
LCD screen is operational from 14 – 131 °F. The sensor may still be programmed in
colder temperatures, but with the remote control.
Cable length/gauge 10' / 26 AWG
Degree of protection IP54
Compliance R&TTE 1999/5/EC; MD 2006/42/EC; LVD 2006/95/EC; ROHS 2 2011/65/EU
Specifications are subject to change without prior notice.
All values measured in specific conditions.
TECHNICAL SPECIFICATIONS
