3 Quick Start
3.1 Setup
Note: The instrument will not heat, cool, or control until the “SET PT.”
parameter is “Enabled”.
Place the block on a at surface with at least 15 cm (6 in) of free space around the in-
strument. Overhead clearance is required. DO NOT place under a cabinet or structure.
Plug the instrument power cord into a mains outlet of the proper voltage, frequency,
and current capability (see Section 2.1, Specications, on page 11 for power details).
Observe that the nominal voltage corresponds to that indicated on the front of the
block.
Carefully place the insert into the well. Inserts should be of the smallest hole diam-
eter possible still allowing the probe to slide in and out easily. Various insert sizes
are available. Contact an Authorized Service Center for assistance (see Section 1.6,
Authorized Service Centers, on page 9). The well must be clear of any foreign objects,
dirt and grit before an insert is installed. The insert is installed with the two small tong
holes positioned upward.
Turn on the power to the block by toggling the switch on the power entry module.
After a brief self-test, the controller should begin normal operation. The main screen
appears within 30 seconds. If the instrument fails to operate, please check the power
connection. The display shows the well temperature, and waits for user input before
further operation.
Press “SET PT.” and use the arrow keys to set the desired set-point temperature. Press
“ENTER” to save the desired set-point and enable the instrument. After ve (5) sec-
onds, the instrument should start to operate normally and heat or cool to the designated
set-point.
