Device Configuration
VPN – L2TP (Example on Remote Dial-in)
96
BEC MX-200 User Manual
Example: L2TP VPN – Remote Employee Dial-in to MX-200
A remote worker establishes a L2TP VPN connection with the head office using Microsoft's VPN
Adapter (included with Windows XP/2000/ME, etc.). The router is installed in the head office,
connected to a couple of PCs and Servers.
The input IP address 192.168.1.200 will be assigned to the remote worker. Please make sure this IP is
not used in the Office LAN.
Configuration Settings
Description
Connection Name
HS-RA
Give a name of L2TP connection
Connection Mode
Dial in
Operate as L2TP server
Authentication Type
Chap/Pap
Authentication type
Username
test
Dial in authenticate user name
Password
test
Dial in authenticate user password
Assigned IP
192.168.1.200
An IP assigned to the dial in client
Connection Type
Remote Access
Remote access for dial in
