Device Configuration
VPN – L2TP (Example on Remote Dial-out)
97
BEC MX-200 User Manual
Example: L2TP VPN – MX-200 Dial-out to a Server
A company’s office establishes a L2TP VPN connection with a file server located at a separate
location. The router is installed in the office, connected to a couple of PCs and Servers.
Item
Description
Connection Name
HC-RA
Give a name of L2TP connection
Connection Mode
Dial out
Operate as L2TP client
Server IP
69.121.1.33
Dialed server IP address
Authentication Type
Chap/Pap
Authentication type
Username
test
Dial out authenticate user name
Password
test
Dial out authenticate user password
Connection Type
Remote Access
Remote access for dial out
