Device Configuration
VPN – PPTP (Example on LAN-to-LAN)
93
BEC MX-200 User Manual
Configuring PPTP Client in the Branch office
The IP address 69.1.121.33 is the Public IP address of the router located in head office.
Configuration Settings
Description
Connection Name
BC-LL
Give a name of PPTP connection
Authentication Type
MPPE 128bit
Authentication type
Username
test
Dial in authenticate user name
Password
test
Dial in authenticate user password
Connection Type
LAN to LAN
LAN to LAN for dial in
Server IP
69.121.1.33
Dialed server IP
Remote Network IP
129.168.1.0
Remote access network
Remote Network Netmask
255.255.255.0
