General
These tubular drives are high-quality products with the following features:
• Optimised for vertical ZIP applications
• Individual, group and central radio control
• No need to run wires to a switch or relay control device
• Any combination of drive and transmitter possible
• Simple to set the limit positions with the transmitter
• Two freely selectable intermediate positions can be set
• Flexible radio grouping; can be altered at any time with no need to install/uninstall
• Integrated memo function facilitates easy programming of one or two switching times on daily repeat.
• Installation without stops possible (from extended point to retracted point)
• Automatic detection of limit positions thanks to intelligent electronic system with stop systems
• The limit positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
• Suitable for vertical sun protection
• Considerably reduced stop load, and thus considerably reduced fabric load
• Activate/deactivate the fabric untensioning function
• Left or right hand installation
• Several drives can be operated in parallel
• Automatic adjustment of direction of rotation
• Smooth operation of the system and the drive increases the service life
• For plug-in connecting cable
Please follow these Assembly and Operating Instructions when installing and setting up the device.
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 34th calendar week in 2020
Ser. No.: 2034XXXXX
Explanation of pictograms
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in injury.
ATTENTION
ATTENTION indicates measures that must be taken to avoid damage to
property.
Denotes user tips and other useful information.
3-en
