Compatible Centronic transmitters
All CentronicPlus receivers can be operated with the Centronic transmitters listed in the Centronic/CentronicPlus compatibility
table at
www.becker-antriebe.com/downloads
As two fundamentally different radio technologies are linked in this case, the full performance of the CentronicPlus radio control
system is not available in this combination. When using the Centronic transmitter with CentronicPlus receiver, the range perform-
ance may be reduced under certain circumstances. A Centronic transmitter cannot process feedback from the CentronicPlus re-
ceiver. The full performance of CentronicPlus is only achieved in combination with CentronicPlus transmitters, receivers and
sensors, as only then will an intelligent, bidirectional system be automatically created.
Commissioning with a CentronicPLUS transmitter
Explanation of symbols
UP button
STOP button
DOWN button
Programming button (on the transmitter)
Function button (on the transmitter)
LED ring on the transmitter
Receiver confirms once or multiple times by “clicking” or “shifting”
1 = direction switch
2 = radio switch
Operating modes
Normal mode Control of selected receiver/ channel
Receiver selection Selection of the required receiver and channel allocation
Setting mode Commissioning and administration of selected receivers
Attention
The tubular drives are designed for short-time operation. An inbuilt thermal protection
switch prevents overheating of the tubular drive. During commissioning (long drop dis-
tance or long running time), the thermoswitch may trigger. The drive will switch off. After a
short cooling-down period, the system is ready for operation again.
The drive does not achieve its full duty cycle until it has cooled to ambient temperature.
Avoid a situation where the thermal protection switch cuts in repeatedly.
9-en
