Disposal
The crossed-out bin symbol on the product indicates that the device is subject to mandatory disposal separate from household
waste. This product must be handed over to a collection point for electrical and electronic equipment at the end of its service life.
The packaging material must be disposed of properly.
Maintenance
These drives are maintenance-free.
Technical data dia. 35
Tubular drive P5-20 P5-30 P9-16
Model C18 PLUS
Type C PSOF1 Z1
Rated torque [Nm] 5 5 9
Output speed [rpm] 20 30 16
Limit switch range 64revolutions
Supply voltage 230VAC/50Hz
Connected load [W] 115 115 110
Rated current consumption [A] 0.47 0.47 0.47
Operating mode S24min.
Degree of protection IP 44
Min. tube inside diameter [mm] 37
Frequency 868.3 MHz
Emission sound pressure level [dB(A)] ≤ 70
Technical data dia. 45
Tubular drive R8-17 R12-17 R20-17 R30-17 R40-17
Model C18 PLUS
Type C PSOF1 Z1
Rated torque [Nm] 8 12 20 30 40
Output speed [rpm] 17 17 17 17 17
Limit switch range 64revolutions
Supply voltage 230VAC/50Hz
Connected load [W] 100 110 160 205 260
Rated current consumption [A] 0.45 0.50 0.75 0.90 1.15
Operating mode S24min.
Degree of protection IP 44
Min. tube inside diameter [mm] 47
Frequency 868.3 MHz
Emission sound pressure level
[dB(A)]
≤ 70
