Behringer DEEPMIND 12 User Manual

107 DeepMind 12 User Manual
FlangeVerb (FLANGER & REVERB)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* SPD Speed Hz 0.0 Hz 4.0 Hz Adjusts the rate of the anger. Time synchronised options from 4 to 1/64 bars.
2* DEP Depth % 0.0% 100% Adjusts the modulation depth of the anger.
3 DLY Delay ms 0.5 ms 20.0 ms Adjusts the delay of the anger.
4* PHS Phase — 0.0 180.0 Osets the phase between the left and right channels.
5* FBK Feed % -90.0% 90.0% Controls the percentage of positive or negative feedback.
6* BAL Balance — -100.0 100.0 Adjusts the balance between anger and reverb.
7 PRE PreDelay ms 0.0 200.0 ms Controls the amount of time before the reverb is heard following the source signal.
8* DCY Decay s 0.1 s 5.0 s Controls the amount of time it takes for the reverb to dissipate.
9 SIZ Size — 2.0 200.0 Controls how large or small the simulated space is.
10* DMP Damping Hz 1000 Hz 20000 Hz Determines the decay of high frequencies within the reverb tail.
11* LC LoCut Hz 10.0 Hz 500.0 Hz Excludes low frequencies below the value.
12* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
* These parameters are available as modulation destinations in the Modulation Matrix
MidasEQ (MIDAS EQUALIZER)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* LSG LoShelfGain dB -12.0 dB 12.0 dB Adjusts the gain of the low band.
2* LSF LoShelfFreq Hz 30.0 Hz 20000.0 Hz Adjusts the frequency of the low band.
3* LMG LoMidGain dB -12.0 dB 12.0 dB Adjusts the gain of the low-mid band.
4* LMF LoMidFreq Hz 30.0 Hz 20000.0 Hz Adjusts the frequency of the low-mid band.
5* LMQ LoMidQ — 0.3 5.0 Adjusts the Q-factor of the low-mid band.
6* HMG HiMidGain dB -12.0 dB 12.0 dB Adjusts the gain of the high-mid band.
7* HMF HiMidFreq Hz 30.0 Hz 20000.0 Hz Adjusts the frequency of the high-mid band.
8* HMQ HiMidQ — 0.3 5.0 Adjusts the Q-factor of the high-mid band.
9* HSG HiShelfGain dB -12.0 dB 12.0 dB Adjusts the gain of the high band.
10* HSF HiShelfFreq Hz 30.0 Hz 20000.0 Hz Adjusts the frequency of the high band.
11* EQ EQ — IN OUT Adjusts the frequency of the high band.
* These parameters are available as modulation destinations in the Modulation Matrix
