106 DeepMind 12 User Manual

ChorusVerb (CHORUS & REVERB)

No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION

1* SPD Speed Hz 0.0 Hz 4.0 Hz Adjusts the rate of the chorus. Time synchronised options from 4 to 1/64 bars.

2* DEP Depth % 0.0% 100% Adjusts the modulation depth of the chorus.

3 DLY Delay ms 0.5 ms 50.0 ms Adjusts the delay of the chorus.

4* PHS Phase — 0.0 180.0 Osets the phase between the left and right channels.

5 WAV Wave % 0.0% 100% Adjusts the LFO waveform from a sine wave to triangular wave.

6* BAL Balance — -100.0 100.0 Adjusts the balance between chorus and reverb.

7 PRE PreDelay ms 0.0 200.0 ms Controls the amount of time before the reverb is heard following the source signal.

8* DCY Decay s 0.1 s 5.0 s Controls the amount of time it takes for the reverb to dissipate.

9 SIZ Size — 2.0 200.0 Controls how large or small the simulated space is.

10* DMP Damping Hz 1000 Hz 20000 Hz Determines the decay of high frequencies within the reverb tail.

11* LC LoCut Hz 10.0 Hz 500.0 Hz Excludes low frequencies below the value.

12* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.

* These parameters are available as modulation destinations in the Modulation Matrix

DelayVerb (DELAY & REVERB)

No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION

1 TIM Time ms 1.0ms 1500.0ms Adjusts the delay time for the left channel delay. Time sync options from 4 to 1/64 bars.

2 PAT Pattern — 1/4 1X Sets the delay ratio for the right channel delay.

3* FHC FeedHC Hz 200.0 Hz 20000.0 Hz Trims high frequencies from the feedback.

4* FBK Feedback % 0.0% 100% Controls the percentage of feedback.

5* XFD X-Feed % 0.0% 100% Control the amount of delay sound sent to the reverb eect.

6* BAL Balance — -100.0 100.0 Adjusts the ratio between delay and reverb.
