111 DeepMind 12 User Manual
NoiseGate (NOISE GATE)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* THR Threshold dB -50.0 0.0 Sets signal level at which gate opens.
2* RNG Range dB -100.0 0.0 Control adjusts the amount of gain reduction applied to the signal below threshold.
3* ATT Attack ms 0.0 20.0 Adjusts time taken for gate to open after an over-threshold signal.
4* REL Release ms 2.0 1999.9 Adjusts time taken for gate to close after programme material falls back below threshold.
5* HLD Hold ms 2.0 1999.9 This denes a waiting period before the gate starts to close.
6* PUN Punch — -6.0 6.0 Used to increase tonal shaping or reduce gated breathing/delay/resonant howl-round.
7 MOD Mode — — — GAT (Gate), TRN (Transient Gate), DUC (Ducker).
8 PWR Power — ON OFF Enables gate in the signal path. When switched o, gate is bypassed.
* These parameters are available as modulation destinations in the Modulation Matrix
Delay (STEREO DELAY)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
2 TIM Time ms 1.0 ms 1500.0 ms Adjusts the master delay time. Time synchronised options from 4 to 1/64 bars.
3 MOD Mode — — —
ST- Stereo feedback, X - crosses feedback between channels, M - Mono mix in feedback chain.
P-P - Ping Pong (Note that Feedback-R (FBR) is disabled in this mode.
4 FCL FactorL — — — Sets left delay to rhythmic fractions of the master delay (¼ ⁄ ½ ⁄, 1, ⁄ ⁄, 2, 3).
5 FCR FactorR — — — Sets right delay to rhythmic fractions of the master delay (¼ ⁄ ½ ⁄, 1, ⁄ ⁄, 2, 3).
6 OFS Oset ms -100.0 ms 100.0 ms Adds a delay dierence between the left and right delayed signals.
7* LC LC Hz 10.0 Hz 500.0 Hz Adjusts the low frequency cut, allowing lower frequencies to remain unaected by the delay.
8* HC HC Hz 200.0 Hz 20000.0 Hz Adjusts the high frequency cut, allowing higher frequencies to remain unaected by the delay.
9* FLC FeedLC Hz 10.0 Hz 500.0 Hz Adjusts the low cut lter frequency in the feedback paths.
10* FBL FeedL % 0.0% 100% Control the amount of feedback for the left channel.
11* FBR FeedR % 0.0% 100% Control the amount of feedback for the right channel.
12* FHC FeedHC Hz 200.0 Hz 20000.0 Hz Adjusts the high cut lter frequency in the feedback paths.
* These parameters are available as modulation destinations in the Modulation Matrix
