Behringer DEEPMIND 12 User Manual

110 DeepMind 12 User Manual
EdisonEX1 (STEREO IMAGING)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1 ON On — OFF ON Allows the eect to be turned On or O.
2 IMD InMode — ST M/S Controls the input mode (Stereo or Mid/Side).
3 OMD OutMode — ST M/S Controls the output mode (Stereo or Mid/Side).
4* STS StSpread — -50.0 50.0 Controls the spread of the stereo eld.
5* LMF LMFSpread — -50.0 50.0 Controls the spread of the stereo eld for low/mid frequencies only.
6* BAL Balance — -50.0 50.0 Adjusts the ratio of mono to stereo content.
7* CNT CntrDist — -50.0 50.0 Allows the mono content to be panned.
8* GN Gain dB -12.0 dB 12.0 dB Controls the amount of output gain applied to the signal.
* These parameters are available as modulation destinations in the Modulation Matrix
Auto Pan (AUTO PANNING)/Tremolo
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* SPD Speed Hz 0.0 Hz 5.0 Hz Adjusts the LFO rate. Time synchronised options from 4 to 1/64 bars.
2* PHS Phase — 0.0 180.0 Controls the LFO phase dierence between the left and right channels.
3* WAV Wave — -50.0 50.0 Blends the LFO waveform between triangular and square shape.
4* DEP Depth % 0.0% 100% Controls the depth (amount) of modulation.
5* ESP EnvSpd % 0.0% 100% Adjusts how much the LFO speed is modulated by the envelope.
6* EDP EnvDepth % 0.0% 100% Adjusts the depth of the envelope modulation.
7* ATK Attack ms 10.0 ms 1000.0 ms Controls the envelope attack stage time.
8* HLD Hold ms 1.0 ms 2000.0 ms Controls the envelope hold stage time.
9* REL Release ms 10.0 ms 1000.0 ms Controls the envelope release stage time.
* These parameters are available as modulation destinations in the Modulation Matrix
