113 DeepMind 12 User Manual
T-RayDelay (TEL-RAY DELAY)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
2* DLY Delay % 0.0% 100% Adjusts the master delay time.
3* SUS Sustain % 0.0% 100% Controls how long the delay is sustained for. Warning at 100% build up will occur.
4* WOB Wobble % 0.0% 100% Adjusts the amount of wobble caused by age and quality of build/materials.
5* TON Tone % 0.0% 100% Controls the tone of the delays.
* These parameters are available as modulation destinations in the Modulation Matrix
DecimDelay (Decimator Delay)
No DM12 REF PARAMETERS UNITS MIN MAX DESCRIPTION
1*
MIX Mix % 0.00% 100.00% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
2
TIM Time Ms 1.0 ms 1500.0 ms Adjusts the master delay time. Time synchronized options from 4 to 1/64 bars.
3*
DSM
Downsample
% 0.00% 100.00% Decimates the signal by reducing the sampling frequency.
4
FCL FactorL — — — Sets left delay to rhythmic fractions of the master delay (¼ ⁄ ½ ⁄, 1, ⁄ ⁄, 2, 3).
5
FCR FactorR — — — Sets right delay to rhythmic fractions of the master delay (¼ ⁄ ½ ⁄, 1, ⁄ ⁄, 2, 3).
6
BRC Bit-Reduce — 24 1 Decimates the signal by reducing the bit-depth.
7*
FC Cuto Hz 30.0 Hz 20000.0 Hz
Adjust the cuto frequency of the lter, allowing specic frequencies to be aected
by the delay.
8*
RES Resonance % 0.00% 100.00% Adjusts the resonance of the lter.
9
FLT Type — — — It sets the lter type (Lowpass, Highpass, Bandpass, Notch).
10*
FBL FeedL % 0.00% 100.00% Controls the amount of feedback for the left channel.
11*
FBR FeedR % 0.00% 100.00% Controls the amount of feedback for the right channel.
12
DMT Decimate — — — It sets the decimation on the input signal (PRE) or only on the delay (POST).
* These parameters are available as modulation destinations in the Modulation Matrix
