118 DeepMind 12 User Manual
RotarySpkr (ROTARY SPEAKER)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* LOS LoSpeed Hz 0.1 Hz 4.0 Hz Adjusts the rotational speed when the Low Speed operation is selected.
2* HIS HiSpeed Hz 2.0 Hz 9.9 Hz Adjusts the rotational speed when the High Speed operation is selected.
3* ACC Accel % 0.0% 100% Adjusts how quickly the speed increases and decreases from the Slow mode to the Fast mode.
4* DIS Distance % 0.0% 100% Adjusts the distance between the Rotary speakers and the virtual microphone.
5* BAL Balance — -100.0 100.0 Adjusts the balance between the virtual horn and virtual drum controlling the signal tone.
6* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
7* MOT Motor — RUN STOP Allows The rotation eect of the motor to be disengaged (STOP).
8* SPD Speed — SLOW FAST Selects either the slow or fast speeds for rotation.
* These parameters are available as modulation destinations in the Modulation Matrix
