117 DeepMind 12 User Manual
Dual Pitch (DUAL PITCH SHIFTER)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* SM1 Semi1 — -12.0 12.0 Adjusts the pitch of the rst channel in semi-tones.
2* CN1 Cent1 — -50.0 50.0 Adjusts the pitch of the rst channel in cents.
3 DL1 Delay1 ms 1.0 ms 500.0 ms Adjusts the time dierence between the wet and dry signals. Sync options from 4 to 1/64 bars.
4* GN1 Gain1 % 0.0% 100% Allows gain compensation to be applied to the rst channel.
5* PN1 Pan1 % -100.0% 100% Allows panning of the rst channel.
6* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
7* SM2 Semi2 — -12.0 12.0 Adjusts the pitch of the second channel in semi-tones.
8* CN2 Cent2 — -50.0 50.0 Adjusts the pitch of the second channel in cents.
9 DL2 Delay2 ms 1.0 ms 500.0 ms Adjusts the time dierence between the wet and dry signals. Sync options from 4 to 1/64 bars.
10* GN2 Gain2 % 0.0% 100% Allows gain compensation to be applied to the second channel.
11* PN2 Pan2 % -100.0% 100% Allows panning of the second channel.
12* HIC HiCut Hz 200.0 Hz 20000.0 Hz Allows the high frequencies aected by the pitch shifting to be reduced.
* These parameters are available as modulation destinations in the Modulation Matrix
Vintage Pitch (DUAL PITCH SHIFTER)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* SM1 Semi1 — -12.0 12.0 Adjusts the pitch of the rst channel in semi-tones.
2* CN1 Cent1 — -50.0 50.0 Adjusts the pitch of the rst channel in cents.
3 DL1 Delay1 ms 1.0 ms 500.0 ms Adjusts the time dierence between the wet and dry signals. Sync options from 4 to 1/64 bars.
4* FB1 Feedback1 % 0.0% 100% Allows feedback to be applied to the rst channel.
5* PN1 Pan1 % -100.0% 100% Allows panning of the rst channel.
6* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
7* SM2 Semi2 — -12.0 12.0 Adjusts the pitch of the second channel in semi-tones.
8* CN2 Cent2 — -50.0 50.0 Adjusts the pitch of the second channel in cents.
9 DL2 Delay2 ms 1.0 ms 500.0 ms Adjusts the time dierence between the wet and dry signals. Sync options from 4 to 1/64 bars.
10* FB2 Feedback2 % 0.0% 100% Allows feedback to be applied to the second channel.
11* PN2 Pan2 % -100.0% 100% Allows panning of the second channel.
12* HIC HiCut Hz 2000Hz 20000 kHz Allows the high frequencies aected by the pitch shifting to be reduced.
* These parameters are available as modulation destinations in the Modulation Matrix
