Beko DRYPOINT M intelligence - Replacing Control Unit; Replacing Float Drain

US-EN Installation and operation instructions
DRYPOINT
®
M intelligence 29
7.1.3. Replacing control unit
If your control unit is not working properly, contact BEKO TECHNOLOGIES GmbH or one of its agents. Have the serial
number printed on the name plate handy.
If an exchange of the control unit is required as a result of assessing the situation, then you will receive the installation
instructions with the new control unit.
7.1.4. Replacing oat drain
If the oat drain is defective, it must be replaced.
1. Close the shut-o valves (1) and open the shut-o valve (2) of the bypass.
2. Hold the top part of the housing, unscrew the housing extension (3) and remove it (4).
1
2
1
4
3
For detailed instructions for the replacement of the oat drain, refer to the instruction sheet shipped with the spare part.
