Beko DRYPOINT M intelligence - Technical Data

Installation and operation instructions US-EN
16 DRYPOINT
®
M intelligence
2.8. Technical data
Technical data
MDi 12 MDi 17 MDi 25 MDi 35 MDi 45 MDi 55 MDi 65 MDi 100 MDi 130
Min./max. operating overpressure 58 ... 145 psi
Overpressure protection housing Ventilation screw with check valve (opening pressure approx. 3 psi)
Min./max.
storage/transport temperature
+35 ... +122 °F
Min./max. Ambient temperature +35 ... +122 °F
Min./max. Media temperature +35 ... +122 °F
Medium Fluid group 2: Compressed air/nitrogen
Media and quality at the inlet of
the membrane dryer
Only neutral media in accordance with DGRL 2014/68/EU of the class [3: - :3] ISO 8573-1
Noise level << 45 dB (A), for switching operation of solenoid valve < 60 dB (A)
Installation position vertical
Weight 7.5 lbs 7.9 lbs 10.8 lbs 11.4 lbs 12.1 lbs 12.8 lbs 24.0 lbs 26.4 lbs 28.8 lbs
Materials Media-contacting parts corrosion-proof
Materials conforming to RoHS and REACH regulations
Plastic components conforming to UL regulations
Integrated nanolter 0.01 µm / 0.005 mg/m³
Pressure loss
2 - 5 psi, depending on compressed air volume flow
PDP outlet settings +50 / +45 / +40 / +37 / +32 / +23 / +14 / +5 / -5 / -15 °F
PDP dierence settings 20 / 27 / 35 / 45 / 55 / 65 / 72 / 80 / 90 / 100 °F (Fahrenheit)
Electrical data
Power consumption max. 20 VA (W) with permanently closed solenoid valve
Recommended strand cross-sec-
tion
AWG 21
Recommended power cable 2-strand, diameter 0.19 ... 0.39 inch
Protection class control unit IP 54
Min./max. Contact spring load
(potential-free contact)
max. 12 VAC / 1 A oder 24 VDC / 1 A ; min. 5 VDC / 10 mA
Signal output 4 … 20 mA (PDP output)
Interfaces 2 x cable connection M16, cable diameter 0.19 ... 0.39 inch
Operating voltage
95 ... 240 VAC ± 10% (50 ... 60 Hz) / 100 ... 125 VDC ± 10%
Electrical data
MDi 12-LV MDi 17LV MDi 25-LV MDi 35-LV MDi 45 -LV MDi 55 -LV MDi 65 -LV
MDi 100 -
LV
MDi 130 -
LV
Operating voltage 24 ... 48 VAC ± 10% (50 ... 60 Hz) / 18 ... 72 VDC ± 10%
