Beko DRYPOINT M intelligence - Page 17

US-EN Installation and operation instructions
DRYPOINT
®
M intelligence 17
PDP inlet Volume ow inlet in cfm at 145 psi
+100 °F +40 °F MDi 12 MDi 17 MDi 25 MDi 35 MDi 45 MDi 55 MDi 65 MDi 100 MDi 130
+50 °F +14 °F 12.9 17.2 26.0 34.5 48.7 56.6 67.5 101.1 134.7
+40 °F +5 °F 10.9 14.5 21.7 29.0 41.4 47.9 57.5 87.4 115.9
+32 °F
9.7 13.0 19.5 25.9 37.2 43.3 52.1 79.5 105.5
-4 °F
9.5 12.6 19.0 25.3 36.3 42.3 50.8 77.6 103.2
+23 °F
8.8 11.7 17.6 23.5 33.6 39.4 47.5 72.6 96.5
+14 °F -15 °F 8.1 10.8 16.2 21.6 30.8 36.2 44.0 67.0 88.8
+5 °F
7.5 9.9 14.9 19.9 28.5 33.4 40.7 61.8 82.0
-4 °F
7.0 9.3 14.0 18.6 26.7 31.4 38.1 57.8 76.8
-15 °F
6.5 8.6 13.0 17.3 24.8 28.9 35.4 53.8 71.8
DTP outlet 1.5 1.9 2.9 3.9 5.6 6.5 7.9 12.1 15.9
145 psi Purge air in cfm at 145 psi
* The intrinsic permeability is app. 5% of the purge air volume.
PDP inlet Volume ow inlet in cfm at 130 psi
+100 °F +40 °F MDi 12 MDi 17 MDi 25 MDi 35 MDi 45 MDi 55 MDi 65 MDi 100 MDi 130
+50 °F +14 °F 11.1 14.8 22.5 29.8 42.1 48.9 58.4 87.3 116.4
+40 °F +5 °F 9.4 12.5 18.8 25.1 35.8 41.4 49.7 75.5 100.1
+32 °F
8.4 11.2 16.8 22.4 32.2 37.4 45.0 68.7 91.2
-4 °F
8.2 10.9 16.4 21.9 31.3 36.5 43.9 67.1 89.1
+23 °F
7.6 10.2 15.2 20.3 29.1 34.1 41.1 62.7 83.4
+14 °F -15 °F 7.0 9.3 14.0 18.6 26.6 31.3 38.0 57.9 76.7
+5 °F
6.4 8.6 12.9 17.2 24.6 28.9 35.2 53.4 70.8
-4 °F
6.0 8.1 12.1 16.1 23.1 27.1 32.9 50.0 66.4
-15 °F
5.6 7.4 11.3 15.0 21.4 25.0 30.6 46.5 62.1
DTP outlet 1.3 1.7 2.6 3.5 5.0 5.9 7.2 10.9 14.4
130 psi Purge air in cfm at 130 psi
* The intrinsic permeability is app. 5% of the purge air volume.
PDP inlet Volume ow inlet in cfm at 115 psi
+100 °F +40 °F MDi 12 MDi 17 MDi 25 MDi 35 MDi 45 MDi 55 MDi 65 MDi 100 MDi 130
+50 °F +14 °F 9.5 12.6 19.1 25.4 35.8 41.5 49.6 74.2 99.0
+40 °F +5 °F 8.0 10.6 16.0 21.3 30.4 35.2 42.2 64.2 85.1
+32 °F
7.2 9.5 14.3 19.1 27.3 31.8 38.2 58.4 77.5
-4 °F
7.0 9.3 13.9 18.6 26.6 31.1 37.3 57.0 75.8
+23 °F
6.5 8.6 12.9 17.3 24.7 29.0 34.9 53.3 70.9
+14 °F -15 °F 5.9 7.9 11.9 15.8 22.6 26.6 32.3 49.2 65.2
+5 °F
5.5 7.3 11.0 14.6 20.9 24.6 29.9 45.4 60.2
-4 °F
5.1 6.8 10.3 13.7 19.6 23.1 28.0 42.5 56.4
-15 °F
4.8 6.3 9.6 12.7 18.2 21.2 26.0 39.5 52.8
DTP outlet 1.2 1.6 2.4 3.1 4.5 5.3 6.4 9.8 12.9
115 psi Purge air in cfm at 115 psi
* The intrinsic permeability is app. 5% of the purge air volume.
