Beko DRYPOINT M intelligence - Page 18

Installation and operation instructions US-EN
18 DRYPOINT
®
M intelligence
PDP inlet Volume ow inlet in cfm at 100 psi
+100 °F +40 °F MDi 7 MDi 9 MDi 13 MDi 18 MDi 25 MDi 29 MDi 36 MDi 51 MDi 71
+50 °F +14 °F 8.0 10.6 16.1 21.3 30.1 34.9 41.7 62.4 83.2
+40 °F +5 °F 6.7 8.9 13.4 17.9 25.5 29.6 35.5 54.0 71.5
+32 °F
6.0 8.0 12.0 16.0 23.0 26.7 32.1 49.1 65.1
-4 °F
5.9 7.8 11.7 15.6 22.4 26.1 31.4 47.9 63.7
+23 °F
5.4 7.3 10.9 14.5 20.8 24.3 29.3 44.8 59.5
+14 °F -15 °F 5.0 6.7 10.0 13.3 19.0 22.3 27.1 41.3 54.8
+5 °F
4.6 6.1 9.2 12.3 17.6 20.6 25.1 38.2 50.6
-4 °F
4.3 5.8 8.6 11.5 16.5 19.4 23.5 35.7 47.4
-15 °F
4.0 5.3 8.0 10.7 15.3 17.8 21.8 33.2 44.3
DTP outlet 1.1 1.4 2.1 2.8 4.1 4.8 5.8 8.8 11.6
100 psi Purge air in cfm at 100 psi
* The intrinsic permeability is app. 5% of the purge air volume.
PDP inlet Volume ow inlet in cfm at 90 psi
+100 °F +40 °F MDi 7 MDi 9 MDi 13 MDi 18 MDi 25 MDi 29 MDi 36 MDi 51 MDi 71
+50 °F +14 °F 6.2 8.3 12.5 16.6 23.5 27.2 32.5 48.7 64.9
+40 °F +5 °F 5.2 7.0 10.5 14.0 19.9 23.1 27.7 42.1 55.8
+32 °F
4.7 6.2 9.4 12.5 17.9 20.8 25.1 38.3 50.8
-4 °F
4.6 6.1 9.1 12.2 17.5 20.4 24.5 37.4 49.7
+23 °F
4.2 5.7 8.5 11.3 16.2 19.0 22.9 35.0 46.4
+14 °F -15 °F 3.9 5.2 7.8 10.4 14.8 17.4 21.2 32.2 42.8
+5 °F
3.6 4.8 7.2 9.6 13.7 16.1 19.6 29.8 39.5
-4 °F
3.4 4.5 6.7 9.0 12.9 15.1 18.3 27.8 37.0
-15 °F
3.1 4.1 6.3 8.3 11.9 13.9 17.0 25.9 34.6
DTP outlet 1.0 1.3 1.9 2.5 3.7 4.3 5.2 7.9 10.4
90 psi Purge air in cfm at 90 psi
* The intrinsic permeability is app. 5% of the purge air volume.
PDP inlet Volume ow inlet in cfm at 75 psi
+100 °F +40 °F MDi 7 MDi 9 MDi 13 MDi 18 MDi 25 MDi 29 MDi 36 MDi 51 MDi 71
+50 °F +14 °F 4.5 6.0 9.2 12.1 17.1 19.9 23.8 35.6 47.4
+40 °F +5 °F 3.8 5.1 7.7 10.2 14.6 16.9 20.2 30.8 40.8
+32 °F
3.4 4.6 6.8 9.1 13.1 15.2 18.3 28.0 37.1
-4 °F
3.3 4.4 6.7 8.9 12.8 14.9 17.9 27.3 36.3
+23 °F
3.1 4.1 6.2 8.3 11.8 13.9 16.7 25.5 33.9
+14 °F -15 °F 2.8 3.8 5.7 7.6 10.8 12.7 15.5 23.6 31.2
+5 °F
2.6 3.5 5.2 7.0 10.0 11.8 14.3 21.7 28.8
-4 °F
2.5 3.3 4.9 6.6 9.4 11.0 13.4 20.3 27.0
-15 °F
2.3 3.0 4.6 6.1 8.7 10.2 12.4 18.9 25.3
DTP outlet 0.8 1.1 1.6 2.2 3.1 3.7 4.5 6.8 8.9
75 psi Purge air in cfm at 75 psi
* The intrinsic permeability is app. 5% of the purge air volume.
