Beko DRYPOINT M intelligence - Page 19

US-EN Installation and operation instructions
DRYPOINT
®
M intelligence 19
PDP inlet Volume ow inlet in cfm at 60 psi
+100 °F +40 °F MDi 7 MDi 9 MDi 13 MDi 18 MDi 25 MDi 29 MDi 36 MDi 51 MDi 71
+50 °F +14 °F 3.1 4.1 6.3 8.3 11.7 13.6 16.3 24.3 32.4
+40 °F +5 °F 2.6 3.5 5.2 7.0 10.0 11.5 13.8 21.0 27.9
+32 °F
2.3 3.1 4.7 6.2 9.0 10.4 12.5 19.1 25.4
-4 °F
2.3 3.0 4.6 6.1 8.7 10.2 12.2 18.7 24.8
+23 °F
2.1 2.8 4.2 5.7 8.1 9.5 11.4 17.5 23.2
+14 °F -15 °F 1.9 2.6 3.9 5.2 7.4 8.7 10.6 16.1 21.4
+5 °F
1.8 2.4 3.6 4.8 6.9 8.1 9.8 14.9 19.7
-4 °F
1.7 2.2 3.4 4.5 6.4 7.6 9.2 13.9 18.5
-15 °F
1.6 2.1 3.1 4.2 6.0 7.0 8.5 12.9 17.3
DTP outlet 0.7 0.9 1.3 1.8 2.6 3.0 3.7 5.5 7.3
60 psi Purge air in cfm at 60 psi
* The intrinsic permeability is approx. 5% of the purge air volume.
Product selection
Example selection drying result for:
• Volume ow usage air: 6.4 cfm
• Operating pressure: 60 psi
• PDP lowering: +40 °F to -15 °F
Search in the table of the service data 4 bar
Column DTP inlet "+40 °F" up to the line "-15 °F" (DTP outlet)
Search a value in this line, which is larger than the usage air volume ow
M Column MDi 45 meets this requirements with a nominal value of 7.4 cfm
Purge air consumption MDi 45: 2.6 cfm must be deducted from the in lead volume ow
Max. usage air volume ow: 4.8 cfm M Device is too small, larger device MDi 55 must be selected
