Belden HIRSCHMANN BRS32 - Page 28

28
Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
13 ... 14 Configuration of
the second
uplink ports
99 Identical to the standard ports or not present
 Standard ports for BRS20/22:
10/100 Mbit/s
 Standard ports for BRS40/42:
10/100/1000 Mbit/s
M2 1 × DSC multimode socket for 100 Mbit/s F/O
connections
M4 1 × DST multimode socket for 100 Mbit/s fiber
optic connections
S2 1 × DSC singlemode socket for 100 Mbit/s F/O
connections
S4 1 × DST singlemode socket for 100 Mbit/s fiber
optic connections
E2 1 × DSC singlemode (plus) socket for 100 Mbit/s
fiber optic connections
L2 1 × DSC singlemode (LH) socket for 100 Mbit/s
fiber optic connections
G2 1 × DSC singlemode (LH) socket for 100 Mbit/s
fiber optic connections, 200 km
Z6 1 × SFP slot for 100 Mbit/s F/O connections
ZZ 2 × SFP slot for 100 Mbit/s F/O connections
OO 2 × SFP slot for 100/1000 Mbit/s F/O connections
2Q 2 × SFP slot for 100/1000/2500 Mbit/s fiber optic
connections
2T 2 × RJ45 socket for 10/100/1000 Mbit/s Twisted
Pair connections
QT 2 × RJ45 socket for 2500 Mbit/s Twisted-pair
connections
15 (hyphen) –
16 Temperature
range
S Standard 0 °C ... +60 °C (+32 °F ...
+140 °F)
C Standard
with Conformal
Coating
0 °C ... +60 °C (+32 °F ...
+140 °F)
T Extended -40 °C ... +70 °C (-40 °F ...
+158 °F)
E Extended
with Conformal
Coating
-40 °C ... +70 °C (-40 °F ...
+158 °F)
G Extended with
Conformal Coating,
glued
-40 °C ... +70 °C (-40 °F ...
+158 °F)
17 Supply voltage T 2 × 12 V DC ... 24 V DC
U2×24VDC
F 2 × 24 V DC ... 48 V DC + 24 V AC
P 2 × 48 V DC (PoE) / 54 V DC (PoE+)
Item Characteristic Character
istic value
Description
Table 1: Device name and product code
