7.5 Signal contact
Signal contact
Device variants featuring supply voltage with characteristic value F, P and T
Connection type 6-pin terminal block with screw lock
Tightening torque 0.5 Nm (4.4 lb-in)
min. conductor diameter 0.08 mm
2
(AWG 28)
max. conductor diameter 2.5 mm² (AWG12)
Nominal value I
max
=1A at U
max
= 30 V AC (resistive load)
I
max
=1A at U
max
= 60 V DC (resistive load)
according to the UL Standards:
I
max
=0.5A at U
max
= 30 V AC (resistive load)
I
max
=1A at U
max
= 30 V DC (resistive load)
as per ANSI/UL 121201:
See control drawing in chapter “Relevant for use in explosion
hazard areas (Hazardous Locations, Class I, Division 2)” on
page 12
Table 20: Signal contact: device variants featuring supply voltage with characteristic
value F, P and T
Signal contact
Device variants featuring supply voltage with characteristic value U
Connection type 6-pin terminal block with screw lock
Tightening torque 0.5 Nm (4.4 lb-in)
min. conductor diameter 0.08 mm
2
(AWG 28)
max. conductor diameter 2.5 mm² (AWG12)
I
max
=1A at U
max
= 30 V AC (resistive load)
I
max
=0.5A at U
max
= 60 V DC (resistive load)
I
max
=1A at U
max
= 30 V DC (resistive load)
according to the UL Standards:
I
max
=0.5A at U
max
= 30 V AC (resistive load)
I
max
=1A at U
max
= 30 V DC (resistive load)
as per ANSI/UL 121201:
See control drawing in chapter “Relevant for use in explosion
hazard areas (Hazardous Locations, Class I, Division 2)” on
page 12
Table 21: Signal contact: device variants featuring supply voltage with characteristic
value U
