1.6.2 Port status
These LEDs display port-related information.
Note:
For device variants with 4 × RJ45 sockets:
The LEDs are directly located at the ports.
See figure 2 on page 40.
For device variants with 8 × RJ45 sockets:
The LEDs are located on the right side of the device.
See figure 3 on page 41.
See figure 4 on page 41.
For device variants with ports that are DSC/DST sockets and SFP slots:
The LEDs are directly located at the ports.
See figure 3 on page 41.
See figure 4 on page 41.
Figure 2: LED display elements for device variants with 4 × RJ45 sockets
1
1
2
3
4
1
1
2
3
4
2
2
3
3
4
4
LS/DA
-
-
-
-
-
-
-
-
-
