1.7.4 Hardware revision
 Hardware revision 2
BRS device variants marked as "HW: Rev. 2" only support SW versions
as of 08.7.02. You find the revision marking of your device on the side
label.
Figure 9: Revision marking on the side label
 Hardware revision 3
BRS device variants marked as "HW: Rev. 3" only support SW versions
as of 08.7.04. You find the revision marking of your device on the side
label.
Figure 10: Revision marking on the side label
