Installation BRS20/22/30/32/40/42/50/52
Release
12
01/2022
45
Voltage not electrically insulated
Supported file system: FAT32
Note: A USB cable is used exclusively for the configuration of your device.
Note:
The ACA22-USB-C (EEC) storage medium can remain permanently
connected to the device.
1.7.3 Digital input
Figure 8: (1) Connection on the device, (2) terminal block mounted on the device
(front view), tightening torque.
The digital input allows you to capture and forward signals from digital
sensors. In the configuration, you specify how the device uses the digital
input.
You will find detailed information on possible applications and the
configuration of the digital input in the software user documentation. You will
find the software user documentation as PDF files on the Internet at https://
www.doc.hirschmann.com
Note: For PoE device variants, the digital input is only available for device
variants with a wide casing.
See “General data” on page 65.
