70
Installation BRS20/22/30/32/40/42/50/52
Release
12
01/2022
BRS50-00122Q2Q… 570 g (20.10 oz) 1090 g (38.45 oz) medium IP30 IP40 Yes
BRS50-0020QTQT-S;C… not available 1700 g (60 oz) wide not available IP40 Yes
BRS50-0020QTQT-T;E;G... not available 1700 g (60 oz) wide not available IP30 Yes
BRS50-00202Q2Q-S;C... 950 g (33.51 oz) 1520 g (53.61 oz) wide IP30 IP40 Yes
BRS50-00202Q2Q-T;E;G… not available 1520 g (53.61 oz) wide not available IP30 Yes
BRS50-0024QTQT-S;C… not available 1800 g (63.4 oz) wide not available IP40 Yes
BRS50-0024QTQT-T;E;G… not available 1800 g (63.4 oz) wide not available IP30 Yes
BRS50-00242Q2Q-S;C… 1050 g (37 oz) 1620 g (57.14 oz) wide IP30 IP40 Yes
BRS50-00242Q2Q-T;E;G… not available 1620 g (57.14 oz) wide not available IP30 Yes
BRS52 PoE device variants featuring supply voltage with characteristic value U
BRS52-0012QTQT-S;C… not available 1620 g (57.14 oz) wide not available IP40 Yes
BRS52-0012QTQT-T;E;G… not available 1620 g (57.14 oz) wide not available IP30 Yes
BRS52-00122Q2Q-S;C… 800 g (28.21 oz) 1450 g (51.14 oz) wide IP30 IP40 Yes
BRS52-00122Q2Q-T;E;G… not available 1450 g (51.14 oz) wide not available IP30 Yes
BRS52 PoE device variants featuring supply voltage with characteristic value P
BRS52-0012QTQT-S;C… not available 1320 g (46.56 oz) medium not available IP40 No
BRS52-0012QTQT-T;E;G… not available 1470 g (52 oz) wide not available IP30 Yes
BRS52-00122Q2Q-S;C… 550 g (19.4 oz) 1150 g (40.56 oz) medium IP30 IP40 No
BRS52-00122Q2Q-T;E;G… not available 1300 g (45.85 oz) wide not available IP30 Yes
Product name Weight
(Plastic casing)
Weight
(Metal casing)
Casing width
See “Dimension
drawings” on
page 84.
Degree of
protection
(Plastic casing)
Degree of
protection
(Metal casing)
Digital input
available
Table 12: General data
