Installation BRS20/22/30/32/40/42/50/52 Release
12
01/2022
93
M-FAST-SFP-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 55 km ... 140 km
(14.29 mi ...
86.99 mi)
0.18 dB/km
c
18 ps/(nm×km)
SFP-FAST-MM/LC MM 1310 nm 50/125 µm 0 dB ... 8 dB 0 km ... 5 km
(0 mi ... 3.11 mi)
1.0 dB/km 800 MHz
SFP-FAST-MM/LC EEC MM 1310 nm 62.5/125 µm 0 dB ... 11 dB 0 km ... 4 km
(0 mi ... 2.49 mi)
1.0 dB/km 500 MHz×km
SFP-FAST-SM/LC SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 km ... 25 km
(0 mi ... 15.53 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-FAST-SM/LC EEC SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 km ... 25 km
(0 mi ... 15.53 mi)
0.4 dB/km 3.5 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP/Dispersion
-M2, -MM MM 1300 nm 50/125 µm 0 dB ... 8 dB 0 km ... 5 km
(0 mi ... 3.11 mi)
1.0 dB/km 800 MHz×km
-M2, -MM MM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 km ... 4 km
(0 mi ... 2.49 mi)
1.0 dB/km 500 MHz×km
-M4, -NN SM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 km ... 4 km
(0 mi ... 2.49 mi)
1.0 dB/km 500 MHz×km
-S2, -VV SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 km ... 30 km
(0 mi ... 18.64 mi)
0.4 dB/km 3.5 ps/(nm×km)
-S4, -UU SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 km ... 30 km
(0 mi ... 18.64 mi)
0.4 dB/km 3.5 ps/(nm×km)
Table 30: F/O port 100BASE-FX (DSC/DST fiber optic Fast Ethernet Transceiver)
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber
attenuation
BLP/Dispersion
Table 29: F/O port 100BASE-FX (SFP Fiber Optic Fast Ethernet Transceiver)
