Installation BRS20/22/30/32/40/42/50/52 Release
12
01/2022
95
-LX/LC... MM 1310 nm
e
62.5/125 µm 0 dB ... 10.5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
1.0 dB/km 500 MHz×km
-LX/LC... SM 1310 nm 9/125 µm 0 dB ... 10.5 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
f
0.4dB/km 3.5ps/
(nm×km)
-LX+/LC... SM 1310 nm 9/125 µm 5 dB ... 20 dB 14 km ... 42 km
(8.70 mi ...
26.10 mi)
0.4dB/km 3.5ps/
(nm×km)
-LH/LC... LH 1550 nm 9/125 µm 5 dB ... 22 dB 23 km ... 80 km
(14.29 mi ...
49.71 mi)
0.25 dB/km 19 ps/
(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 71 km ... 108 km
(44.12 mi ...
67.11 mi)
0.25 dB/km 19 ps/
(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 71 km ... 128 km
(44.12 mi ...
79.54 mi)
0.21 dB/
km (typically)
19 ps/
(nm×km)
-LH+/LC... LH 1550 nm 9/125 µm 13 dB ... 32 dB 62 km ... 116 km
(38.52 mi ...
72.07 mi)
0.25 dB/km 19 ps/
(nm×km)
-LH+/LC... LH 1550 nm 9/125 µm 13 dB ... 32 dB 62 km ... 138 km
(38.52 mi ...
85.75 mi)
0.21 dB/
km (typically)
19 ps/
(nm×km)
SFP-GIG-LX/LC... MM 1310 nm
g
50/125 µm 0 dB ... 10,5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
1.0 dB/km 800 MHz×km
SFP-GIG-LX/LC... MM 1310 nm
h
62.5/125 µm 0 dB ... 10.5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
1.0 dB/km 500 MHz×km
SFP-GIG-LX/LC... SM 1310 nm 9/125 µm 0 dB ... 10,5 dB 0 km ... 20 km
i
(0 mi ... 12.43 mi)
0,4dB/km 3,5ps/
(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber
attenuation
BLP
c
/
Dispersion
Table 31: F/O port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
